How To Count Unique Paths In A Grid With Obstacles

How To Count Unique Paths In A Grid With Obstacles

An example of dynamic programming

Problem statement

You're given an m x n grid represented as an integer array called grid. In this grid, there is a robot initially located at the top-left corner (i.e., grid[0][0]). The robot's goal is to move to the bottom-right corner (i.e., grid[m-1][n-1]). The robot can only move downwards or to the right at any given point.

The grid contains obstacles and empty spaces, which are marked as 1 or 0 respectively. The robot cannot pass through squares marked as obstacles.

Your task is determining the number of unique paths the robot can take to reach the bottom-right corner while avoiding obstacles.

It's important to note that the test cases are designed in such a way that the answer will always be less than or equal to 2 * 10^9.

Example 1

The obstacle grid of Example 1

Input: obstacleGrid = [[0,0,0],[0,1,0],[0,0,0]]
Output: 2
Explanation: There is one obstacle in the middle of the 3x3 grid above.
There are two ways to reach the bottom-right corner:
1. Right -> Right -> Down -> Down
2. Down -> Down -> Right -> Right

Example 2

The obstacle grid of Example 2

Input: obstacleGrid = [[0,1],[0,0]]
Output: 1

Constraints

  • m == obstacleGrid.length.

  • n == obstacleGrid[i].length.

  • 1 <= m, n <= 100.

  • obstacleGrid[i][j] is 0 or 1.

Solution: Dynamic programming in place

Let us find the relationship between the positions.

If there is no obstacle at the position (row = i, col = j), the number of paths np[i][j] that the robot can take to reach this position is:

np[i][j] = np[i - 1][j] + np[i][j - 1]
  • As long as there is no obstacle in the first row, np[0][j] = 1. Otherwise, np[0][k] = 0 for all k >= j0, where (0, j0) is the position of the first obstacle in the first row.

  • Similarly, as long as there is no obstacle in the first column, np[i][0] = 1. Otherwise, np[k][0] = 0 for all k >= i0, where (i0, 0) is the position of the first obstacle in the first column.

Code

#include <vector>
#include <iostream>
using namespace std;
int uniquePathsWithObstacles(vector<vector<int>>& obstacleGrid)
{
    const int row = obstacleGrid.size();
    const int col = obstacleGrid[0].size();
    vector<vector<int>> np(row, vector<int>(col, 0));
    for (int i = 0; i < row && obstacleGrid[i][0] == 0; i++)
    {
        np[i][0] = 1;
    }
    for (int j = 0; j < col && obstacleGrid[0][j] == 0; j++)
    {
        np[0][j] = 1;
    }
    for (int i = 1; i < row; i++)
    {
        for (int j = 1; j < col; j++)
        {
            if (obstacleGrid[i][j] == 0)
            {
                np[i][j] = np[i - 1][j] + np[i][j - 1];
            }
        }
    }
    return np[row - 1][col - 1];
}
int main()
{
    vector<vector<int>> obstacleGrid = {{0,0,0},{0,1,0},{0,0,0}};
    cout << uniquePathsWithObstacles(obstacleGrid) << endl;
    obstacleGrid = {{0,1},{0,0}};
    cout << uniquePathsWithObstacles(obstacleGrid) << endl;
}
Output:
2
1

Code explanation

This solution computes the number of unique paths in an m x n grid with obstacles using dynamic programming. It initializes a 2D vector np of the same size as obstacleGrid to store the number of unique paths for each cell.

First, it initializes the top row and left column of np. If there are no obstacles in the top row or left column of obstacleGrid, it sets the corresponding cells in np to 1 because there's only one way to reach any cell in the top row or left column.

Then, it iterates through the grid starting from the second row and second column (i.e., indices (1, 1)). For each cell, if there's no obstacle (obstacleGrid[i][j] == 0), it updates the value in np by summing up the values from the cell directly above it and the cell to the left of it. This step efficiently accumulates the number of unique paths while avoiding obstacles.

Finally, the value at np[row-1][col-1] contains the total number of unique paths to reach the bottom-right corner of the grid, which is returned as the result.

Complexity

The time complexity of this solution is O(m*n), where m and n are the grid dimensions, as it iterates through all grid cells once to compute the unique paths efficiently. Dynamic programming avoids redundant calculations and makes this solution efficient even for large grids.

  • Runtime: O(m*n).

  • Extra space: O(m*n).
